Note To Future Self: Lenovo Laptop USB-C Mini Dock Reset

Hello Future Self,

Past Self here leaving you a note since I forgot to do so last time.

The Problem

When running Linux on a Lenovo, there are times where a firmware update will cause problems with the USB-C Mini Dock afterwards. In the previous 2 cases, the USB-C's RTL network will no longer show up as a seen device. External monitors plugged into the dock may also not function correctly, but it only happened once so I am not sure about that.

Diagnosis of the problem is that the system will complain of no internet connection, and commands will show something like the following (output altered):

ssmoogen@ssmoogen-rh:~$ ip addr
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: enp0s31f6: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc fq_codel state DOWN group default qlen 1000
    link/ether ab:cd:12:34:56:78 brd ff:ff:ff:ff:ff:ff
3: wlp82s0: <BROADCAST,MULTICAST> mtu 1500 qdisc noqueue state DOWN group default qlen 1000
    link/ether 9a:bc:de:f1:23:45 brd ff:ff:ff:ff:ff:ff permaddr aa:aa:bb:bb:cc:cc

The part that has confused me at least once before is that the enp0s31f6 says NO-CARRIER which made me believe that the switch had problems. Looking at the USB-C showed that the link light was on and there was traffic. This led me to try various solutions which were wrong.

Attempted Solutions

In trying to diagnosis this in the past, I tried backing out all the firmware updates to see if they would untrigger the bricking of the connection. The fwupdtool worked great to do this, and I was able to back down through 8 firmwares without a hitch. However the network still said it was offline.

Next I went through older kernels and tried booting with a USB stick. All of them continued to show the e1000e as disconnected. Finally I went through the journalctl command to look for previous boots and what networks were shown up.

ssmoogen@ssmoogen-rh:~$ journalctl | grep eth0 | tail -n 100
Apr 20 16:54:37 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: Intel(R) PRO/1000 Network Connection
Apr 20 16:54:37 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: MAC: 13, PHY: 12, PBA No: FFFFFF-0FF
Apr 20 16:54:37 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 enp0s31f6: renamed from eth0
Apr 20 16:54:38 ssmoogen-rh.localdomain kernel: r8152 4-2.1.2:1.0 eth0: v1.12.13
Apr 20 16:54:38 ssmoogen-rh.localdomain kernel: r8152 4-2.1.2:1.0 enp9s0u2u1u2: renamed from eth0
Apr 20 17:09:24 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: (PCI Express:2.5GT/s:Width x1) aa:aa:aa:bb:bb:bb
Apr 20 17:09:24 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: Intel(R) PRO/1000 Network Connection
Apr 20 17:09:24 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: MAC: 13, PHY: 12, PBA No: FFFFFF-0FF
Apr 20 17:09:24 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 enp0s31f6: renamed from eth0
Apr 20 17:13:56 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: (PCI Express:2.5GT/s:Width x1) aa:aa:aa:bb:bb:bb
Apr 20 17:13:56 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: Intel(R) PRO/1000 Network Connection
Apr 20 17:13:56 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 eth0: MAC: 13, PHY: 12, PBA No: FFFFFF-0FF
Apr 20 17:13:56 ssmoogen-rh.localdomain kernel: e1000e 0000:00:1f.6 enp0s31f6: renamed from eth0

The Solution

Matching up the timestamps I see that there was an additional device see before the updates occurred. This was using the r8152 driver but after the firmware updates it no longer showed up. This finally triggered a memory of an email I had seen where someone else had a similar problem. Going through my email archives, I found that the solution they had found was to unplug the USB-C Dock for 1 minute and then plug everything back in. Sure enough, doing this restored the RTL driver and my network was restored. The e1000 was a red herring as it is somewhere internal to the laptop and probably available through a dongle which I forgot about as there doesn't seem to be a RJ-45 jack I could find on the exterior of the laptop.

Anyway, when this happens again, please remember this letter and save yourself 2 hours of firmware resets and kernel reboots. Sometimes completely turning off the hardware (remove all power from the Dock including the laptop) and turning it back on WILL fix the problem.


~1 year to end of EPEL-7

Extra Packages for Enterprise Linux 7

Extra Packages for Enterprise Linux (EPEL) are packages based off of various Fedora releases but built for the various distributions based off of Red Hat Enterprise Linux. In June of 2014, Red Hat Enterprise Linux 7 (EL-7) was released and over the next several months, a focus was made to make the release of EPEL possible. Much of the work was done by Kevin Fenzi and Dennis Gilmore with some additional work by anyone else who had spare time. The initial goal was to make it that core packages needed for Fedora Infrastructure to move its core servers to EL-7 were built. That had been what had been done for the initial releases of EPEL-5 and EPEL-6, and would allow for enough base 'packages' to be built for additional packages to be added by other maintainers.

In comparison to trying to get EPEL-5 working, building for EPEL-7 was fairly easy. The initial distribution came with a large set of shipped development libraries and tooling versus getting added later. Over the years, the EL-7 distribution also gained various newer gcc toolkits via software collections which also helped EPEL maintainers to keep updating software for much of the 10 year lifecycle of EL-7. However, this maintenance has been getting harder over the last 2 years, as more and more software required either newer kernels, glibc, or other libraries that aren't available for an older operating system. [This is similar to what happened with EPEL-5 and EPEL-6 where the last year or so of the repository was more and more packages being removed due to maintenance concerns.]

This ties in with the general end of support for Red Hat Enterprise Linux 7 on June 30, 2024. While final plans for how EPEL-7 will be end of lifed, this is a general outline from how EPEL-5 and EPEL-6 were similarly ended.

  1. There will be regular reminders on mailing lists that the project will no longer be supporting EL-7 after a specified date.
  2. On that date, the following will happen:
    1. The Fedora build system will not allow any more EPEL-7 builds
    2. A final push of all updates will happen to /pub/epel/7/
    3. The current items in /pub/epel/7/ will be archived over to /pub/archive/epel/7.final/
    4. Symbolic links will be made to point /pub/archive/epel/7 to the 7.final
    5. The mirrormanager program which is what yum uses to look for updates will change where it points to to /pub/archive/epel/7/
    6. After a week to allow mirrors to catch up, /pub/epel/7/ will be removed and a line telling people where to find the archived content.
  3. Updates to lists and such explaining what happened will occur.

Why A Year Plus Notice?

EPEL-7 is the largest release that the Fedora project supports. There are about 400,000 Fedora systems seen by countme, and somewhere between 3.4 million and 6.7 million EPEL-7 users (depending on how looks at mirrormanager statistics). Going from the long tail turn off of EPEL-5 and EPEL-6 systems over the years, many of those EPEL-7 systems will take years to move to later releases. Going from past reports, many of the system administrators are not the original admins who set up the machine, and don't even know the OS or its auxiliary repositories like EPEL are no longer updated. Putting up blog posts like this can help:

  • Give admins notice and a case to their management to do updates BEFORE the end of life date.
  • A heads up on why scripts that mirrored content from /pub/epel/7/ will no longer work.
  • Time to mirror the content locally for the inevitable reinstalls because management don't think an update to a newer release is needed.

Whatever the case, good luck to you fellow system administrators.


Compiling openldap for CentOS 8 Stream

Compiling OpenLDAP for EL8 systems

Steps to compile openldap-server for CentOS 8 Stream

The EL8 release did not ship an openldap-server like it did in previous releases. Instead only the client tools and some libraries are included for existing applications. Instead the focus from the upstream provider has been on other LDAP solutions.

This leaves a problem for various sites who have their data in an OpenLDAP system and do not have the time, energy, resources for moving to something else. There are several possible solutions to this:

  1. Continue to use EL5/EL6 even though it is at end of open maintenance.
  2. Continue to use EL7 until it is end of open maintenance around 2024-06-30.
  3. Move to a different distribution which does have working openldap
  4. Compile replacement tools using the Fedora src.rpm which may be closer to the ‘upstream’.
  5. Compile replacement tools using the upstream source.
  6. Compile using the upstream source from https://git.centos.org
  7. [Added after initial post] You can download them from https://koji.mbox.centos.org/koji/

In this tutorial we will work with number 5. At the end we will cover number 6.

Setting up a build environment.

For simplicity sake, we will assume you have a working but minimally installed Fedora 35 or EL8 system (Alma, Oracle, Rocky, etc) which you can do compiles in. If we are using an EL8 system are going to need to get mock and git installed.

$ sudo dnf install https://dl.fedoraproject.org/pub/epel/epel-release-latest-8.noarch.rpm

For Fedora and EL8 systems the following should work the same:

$ sudo dnf install git mock rpm-build
$ sudo usermod -a -G mock $USERNAME
$ newgrp mock

Answer yes to the questions about adding new keys and the packages should be installed to allow for a build to occur. We now need to set up a minimal .rpmmacros file for the next steps:

# uncomment if you want to build in standard homedirectory
#%_topdir %(echo $HOME)/rpmbuild
# comment if want to use standard home directory
%_topdir        %{getenv:PWD}
%_sourcedir     %{_topdir}/SOURCES
#%_sourcedir     %{_topdir}/SOURCES/%{name}-%{version}
%_specdir       %{_topdir}/SPECS
%_srcrpmdir     %{_topdir}/SRPMS
%_builddir      %{_topdir}/BUILD

%__arch_install_post \
    [ "%{buildarch}" = "noarch" ] || QA_CHECK_RPATHS=1 ; \
    case "${QA_CHECK_RPATHS:-}" in [1yY]*) /usr/lib/rpm/check-rpaths ;; esac \

Once we have that in place, the following will get an openldap build going:

$ mkdir -vp ~/EL8-sources/ ~/output-packages/
$ cd ~/EL8-sources/
$ git clone https://git.centos.org/rpms/openldap.git
$ git clone https://git.centos.org/centos-git-common.git
$ cd openldap
$ ../centos-git-common/get_sources.sh
$ rpmbuild -bs SPECS/openldap.spec

Now depending on the host OS you are doing this on, you should see a file like SRPMS/openldap-2.4.46-18.fc35.src.rpm or SRPMS/openldap-2.4.46-18.el8.src.rpm having been created.

$ mock -r centos-stream+epel-next-8-x86_64 --chain --localrepo \
~/output-packages/ SRPMS/openldap-2.4.46-18.fc35.src.rpm

should then attempt to build the packages and will end up with a fully usable repo in ${HOMEDIR}/output-packages/results/centos-stream+epel-next-8-x86_64

If not, then there are probably some steps or problems I missed in this howto :(. At this point you can determine what to do with installing this -server package on the server needing it.

Downloading direct from CentOS.

This is the ‘feed the fisherman versus teaching how to fish’ part of the document.

If you are using CentOS Stream 8, you can download the build packages from the project koji. I expect similar steps can be done for other rebuilds.

  1. dnf list openldap to get which package you are looking for.
  2. Open a window to https://koji.mbox.centos.org/koji/
  3. Type in openldap in the Search box.
  4. Click on the build you would have installed. For this example, we will choose https://koji.mbox.centos.org/koji/buildinfo?buildID=18688 and then scroll down to the architecture you are using.
  5. Right click on the download button for openldap-servers like:https://koji.mbox.centos.org/pkgs/packages/openldap/2.4.46/18.el8/x86_64/openldap-servers-2.4.46-18.el8.x86_64.rpm
  6. Install this package in the package place you want.
  7. When dnf breaks because it can’t upgrade the package due to the upstream updating, go follow step 0 again.


Dealing with RAID arrays

Dear Future Self,

 We have come to another letter where we are going to better document something PastSelf thought it knew, but clearly didn't. In this case we are going to start recovering from a RAID array after a reinstall. For reasons we won't get into, PastSelf had to reinstall the home server for the 2nd time this week. [Let us just say that PastSelf is no longer allowed to use sudo without supervision and move on.] In the reinstall, we could not get the /dev/sdb and /dev/sdc RAID array to be fully recognized and realized that we had also made the original ones too small for what we needed [which is what started the whole problem when we tried to grow a partition but forgot that the external backup always becomes /dev/sda for some reason and /dev/sdb was not the RAID drive but the / drive. Live and learn, live and learn.]

Due to some bad signatures we needed to clear the drives of their current data. This was done by booting from a USB stick (which also becomes /dev/sda in this hardware.... wtf?) and clearing each drive of its signatures.

# wipefs -a /dev/sdb
# wipefs -a /dev/sdc
# wipefs -a /dev/sdd
# cat /proc/mdstat
Personalities :
md127 : inactive sdc1[1](S)
      1464851456 blocks super 1.2
unused devices:


The above failed because the kernel and boot had tried to make them part of a RAID array /dev/md127 but was not able to sync them. I was also unable to

mdadm --stop /dev/md127
for some reason. At this point, PastSelf further broke his oath of primum non nocere by using dd on each of the disks.
# dd if=/dev/zero of=/dev/sdb bs=1024 count=1000000
# dd if=/dev/zero of=/dev/sdc bs=1024 count=1000000
# dd if=/dev/zero of=/dev/sdd bs=1024 count=1000000
A reboot and going into rescue mode still showed that some signatures were there which I realized was due these disks being formatted with GPT and being much more capable of surviving stupidity. However mdadm --stop now worked so I could use gdisk on the drives. I then reinstalled a minimal Alma8.5 onto the box and then did a manual creation of the RAID array:
# gdisk /dev/sdc
GPT fdisk (gdisk) version 1.0.3

Partition table scan:
  MBR: not present
  BSD: not present
  APM: not present
  GPT: not present

Creating new GPT entries.

Command (? for help): n
Partition number (1-128, default 1): 1
First sector (34-3907029134, default = 2048) or {+-}size{KMGTP}:
Last sector (2048-3907029134, default = 3907029134) or {+-}size{KMGTP}:
Current type is 'Linux filesystem'
Hex code or GUID (L to show codes, Enter = 8300): fd00
Changed type of partition to 'Linux RAID'

Command (? for help): w

Final checks complete. About to write GPT data. THIS WILL OVERWRITE EXISTING

Do you want to proceed? (Y/N): y


At this point we were able to get the system ready for creating the RAID partition.

# mdadm --create --verbose /dev/md1 --level=1 --raid-devices=2 /dev/sdb1 /dev/sdc1 --force
mdadm: Note: this array has metadata at the start and
    may not be suitable as a boot device.  If you plan to
    store '/boot' on this device please ensure that
    your boot-loader understands md/v1.x metadata, or use
mdadm: /dev/sdc1 appears to be part of a raid array:
       level=raid1 devices=2 ctime=Thu Dec 30 18:54:28 2021
mdadm: size set to 1953381440K
mdadm: automatically enabling write-intent bitmap on large array
Continue creating array? y
mdadm: Fail to create md1 when using /sys/module/md_mod/parameters/new_array, fallback to creation via node
mdadm: Defaulting to version 1.2 metadata
mdadm: array /dev/md1 started.
[root@xenadu ~]# cat /proc/mdstat
Personalities : [raid1]
md1 : active raid1 sdc1[1] sdb1[0]
      1953381440 blocks super 1.2 [2/2] [UU]
      [>....................]  resync =  0.7% (15491456/1953381440) finish=158.1min speed=204199K/sec
      bitmap: 15/15 pages [60KB], 65536KB chunk

unused devices: <none>
# mdadm --detail --scan
ARRAY /dev/md1 metadata=1.2 name=xenadu.int.smoogespace.com:1 UUID=c032f979:e8e4deda:a590ca5d:820a8548
# mdadm --detail --scan > /etc/mdadm.conf
# echo '/dev/md0 /srv xfs defaults 0 0' >> /etc/fstab

Now wait for the sync to be done, and then start the restore from backups... you know the ones that Past-PastSelf made just in case of this situation. Also Future-Self, could you please write up some ansible playbooks to do this from now on? Future-FutureSelf will appreciate it.

Yours Truly, PastSelf

Getting past EL-{8,9}'s limitations with toolbx

Dear Future Self,

One of the biggest issues with dealing with Enterprise Linux 8 (be it Rocky to Red Hat) is the lack of additional packages which you know are in Fedora. Trying to get them into EL-8 turns into a Sisyphean task of moving the boulder of multiple python/go/ruby/etc packages into EL8 only to find that the RPM macros and other software have changed so much in 2 to 3 Fedora releases you can't. Past self spent the weekend trying to get a simple GO package backported and found that he needed to touch at least 175 src.rpms to make this 'work'. That was just too much for trying to get something else working.

Thankfully, EL8 ships with a tool which will allow to get past most of these problems if you meet the following criteria:

  1. The package must not require any kernel feature not shipped in the EL-8 kernel.
  2. You have lots of disk space available to basically install a second OS.
  3. You can deal with some of the limitations of containers.

The tool which does all this is Container Toolbx which uses podman to create an interactive shell using the runtime space of the OS you want.

$ sudo -i dnf install toolbox
$ toolbox create --distro fedora --release f35 f35
$ cat /etc/system-release
AlmaLinux release 8.5 (Arctic Sphynx)
$ ls
Ansible-smoogespace/  HUGO/  OLD/  Packages/  RPMS/  SSH-AGENT  Website-smoogespace/  go/  yadm-dotfiles/
$ toolbox enter f35
$ ls
Ansible-smoogespace/  HUGO/  OLD/  Packages/  RPMS/  SSH-AGENT  Website-smoogespace/  go/  yadm-dotfiles/
$ cat /etc/system-release
Fedora release 35 (Thirty Five)
$ sudo -i dnf update
< no password asked >
$ sudo -i dnf install {package I want}
$ {package_command}
As can be seen by the example above, toolbx basically puts the container in the home directory in the user but using the userspace of Fedora 35. This allowed me to have some newer commands which allowed for a compiled go package which I couldn't do in EL-8 at the moment. Since go is static, I can then use this package regularly in my EL-8 environment. [I was also able to get past some similar errors in emacs where I had used some package calls from newer emacs which compile elc which works with EL-8 emacs.]


This is not a cure-all. You are basically downloading basic containers and then using overlays to do updates and other magic to make this work. While it is quite likely possible one could make various daemons (say openvpn) work this way, I also expect that the network hell that comes with containers would make it fragile. However when needing fedpkg or some similar command it is easier to use this than try and port all the other 'packages' that it relies on if you have only a couple of hours free.

Anyway, this is the 2nd time I have had to re-discover this in the last 2 years so I figured I had better write a note to future me in 6 months or a year who has to do this again.

Yours truly, Past Self


How to Install CentOS Stream 9 Cloud Image

Dear Future Self,

You have probably started to install a CentOS Stream 9 cloud image, and completely forgot all the things you learned this time around. No worries, past-self is going to write these down for your usage.

First off, download the image you want. On the day we are writing this, the latest image is http://cloud.centos.org/centos/9-stream/x86_64/images/CentOS-Stream-GenericCloud-9-20220207.0.x86_64.qcow2 but it will most likely be something much newer. They don't put a 'latest' in the directory, so open a browser, search for qcow2, and then instead of searching through 4000 entries from 2021-08-30, press the up-arrow and jump to the last entry on the web-page.

Next, we need to use virt-install to get the image imported to where virtual manager will use it. Older versions of CentOS had a default user, but CentOS Stream 9 relies on cloud-init in order set up the root user and password. This is done via the virt-install command IF you have a virt-install after version 3, so need to look at different command for EL8 and Ubuntu 18.

$ sudo virt-install --name guest-cs9 --memory 2048 \
  --vcpus 2 --disk ./CentOS-Stream-GenericCloud-9-20220207.0.x86_64.qcow2 \
  --import --os-type Linux --os-variant centos-stream9 \
  --network default --console pty,target_type=serial --graphics vnc \
  --cloud-init root-password-generate=on,disable=on,ssh-key=/home/ssmoogen/.ssh/id_ecdsa.pub

You can add more cloud init options by creating data-files for meta and user-data. Go to the cloud-init site for that.

Alternative method (ok the one most likely used).

In the case of trying to do this on EL8 or earlier Ubuntu editions, you will need to use the virt-customize command instead. First we have to make sure it is installed.

For Ubuntu:
  $ sudo apt install libguestfs-tools
For EL based distros:
  $ sudo dnf install guestfs-tools

The virt-customize command is meant to alter a non-running image. If you use it on a running one, you will probably have a very dead box afterwards. YOU HAVE BEEN WARNED.

$ virt-customize -v --uninstall cloud-init --selinux-relabel \
  -a CentOS-Stream-GenericCloud-9-20220207.0.x86_64.qcow2 \
  --ssh-inject root:file:/home/ssmoogen/.ssh/id_ecdsa.pub \
  --root-password random |& tee CSG.out
$ grep 'virt-customize.password' CSG.out # for the random set password.
Depending on the OS this may or may not need to be run with sudo. Check the CSG.out file for any extra errors. We sent both standard out and standard error there to make sure it all got captured. After this is done, you can import as working image with:
$ sudo virt-install --name guest-cs9 --memory 2048 \
  --vcpus 2 --disk ./CentOS-Stream-GenericCloud-9-20220207.0.x86_64.qcow2 \
  --import --os-type Linux --os-variant centos-stream9 \
  --network default --console pty,target_type=serial --graphics vnc

And with that, past self is done recording what is needed to be done.


Growth of Fedora Distribution over Time

Growth of the Fedora Distribution over time

There was a conversation in IRC (libera.chat, #fedora-admin) on the amount of disk space that Fedora is using over time. It used to grow astronomically over time, but there was an idea that it might be slowing down.. and then the realization that no one had graphed it. Taking this challenge in hand I decided to look at it. Doing a complete mirror of the data would require me to have a very long time frame and 100+ TB of disk space, but luckily for me, the Fedora mirror system does a du every night and outputs this data to a file, https://dl.fedoraproject.org/pub/DIRECTORY_SIZES.txt

The file covers all the directories that the main download servers have including the archive trees which are where old releases go to live. It also puts it in a ‘human-readable’ format like

egrep '/rawhide$|/releases/[0-9]*$|/updates/[0-9]*$|/updates/testing/[0-9]*$' DIRECTORY_SIZES.txt | egrep -v '^8.0K|^12K|^4.0K|/pub/epel|/pub/alt' > /tmp/dirs
$ grep '/7' /tmp/dirs
71G /pub/archive/fedora/linux/releases/7
55G /pub/archive/fedora/linux/updates/7
1.5G    /pub/archive/fedora/linux/updates/testing/7

The above takes all the directories we want to worry about and avoid /pub/alt which is a wild west of directories and data. I also want to avoid /pub/epel so I don’t get a mix between EPEL-7 and Fedora Linux 7. It also allows me to save that entire long grep into a file so I don’t repeat if for every time I do the next data manipulation which is:

# Thanks to https://gist.github.com/fsteffenhagen/e09b827430956d7f1de35140111e14c4
grep '/7' /tmp/dirs | numfmt --from=iec | awk 'BEGIN{sum=0} {sum=sum+$1} END{num=split($0,a,"/"); print sum,a[num]}' | numfmt --to=iec
128G 7

This uses a command numfmt that I wish I had known years before as I have ‘replicated’ it repeatedly poorly in awk and python. The first one converts it to an integer, then feeds it to awk which adds it, and then sums all that and prints the output. The conversion is lossy but ok for a quick blog post.

$ cat foobaz.sh

for i in $( seq 7 35 ); do
     grep "/${i}$" /tmp/dirs | numfmt --from=iec | awk 'BEGIN{sum=0} {sum=sum+$1} END{num=split($0,a,"/"); print sum,a[num]}' | numfmt --to=iec | awk '{print $2","$1}'
$ bash foobaz.sh

This first run found a problem because 35 should be greater than 200G. However only /pub/fedora/linux/updates/35 and /pub/fedora/linux/updates/testing/ are publically readable. Getting some data from root and we correct this to 35 having 917G. Plotting this in openoffice with some magic we get:

This is ok for a textual map but how about a graph picture. For this we remove the conversion to human readable data (aka M,G,T) and put the data into openoffice for some simple bar graphs. And so here is our data:


After this we can also look at how someone mirroring the distributions over time need more disk space:

The total growth looks to be move from exponential to linear over time. If you wanted to break out into smaller archives, you could put release 1 to 25 on one 10 TB drive, and 26 to 32 on another 10 TB drive as the releases after 26 are usually 1.4 TB in size at the end of their release cycle.
